Mounting the device under a metal desk
NOTE
When mounting the device on a vertical metal surface, Brocade recommends that you mount the
device with the port side down.
CAUTION
Do not mount the ICX 6430-C device directly underneath a desktop surface with the top panel
facing downward. Only mount the ICX 6430-C device underneath a desktop by attaching it to
the metal side surface of the desk, with the front panel and ports facing downward.
Complete the following steps to securely mount an ICX 6430-C device under a metal desktop:
Mounting the device under a metal desk
32
Brocade ICX 6430-C Compact Switch Hardware Installation Guide
53-1003080-01
