Brocade VDX 6730 Hardware Reference Manual

31

53-1002389-06

POST and boot specifications

4

POST and boot specifications

When the switch is turned on or rebooted, the switch performs a power-on, self-test (POST). Total
boot time with POST can be several minutes. POST can be omitted after subsequent reboots by
using the fastboot command or entering the no diag post command to persistently disable POST.

For more information about these commands, refer to the Brocade Network OS Command
Reference
.

POST

The success or failure results of the diagnostic tests that run during POST can be monitored
through LED activity, the error log, or the command line interface.

POST includes the following tasks:

Conducts preliminary POST diagnostics.

Initializes the operating system.

Initializes hardware.

Runs diagnostic tests on several functions, including circuitry, port functionality, memory,
statistics counters, and serialization.

Fan status (one
bicolor LED
{green and
amber] per fan
assembly)(Broca
de VDX 6730-76)

Off (no light)

Fan assembly is not receiving
power.

Try the following:

Verify the fan assembly is seated
correctly.

Verify the switch is powered on.

Steady green

Fan assembly is operating
normally.

No action required.

Steady amber
(for more than 5
seconds)

Fan fault for one of the following
reasons:

Mismatched airflow on fan
assemblies.

One or more of the fans in
the fan assembly has failed

The fan assembly was
disabled by the user

NOTE: When the switch is first

powered on, the fan
status LED will show
amber until POST has
completed.

Try the following:

Verify that the airflow symbol and
part number on the replacement
fan matches the fans in the
chassis. Replace if necessary.

Replace the fan assembly.

Verify the fan assembly is enabled
(use the show environment fan
command).Re-enable if
necessary.

TABLE 4

Non-port side LED patterns during normal operation (Continued)

LED name

LED color

Status of hardware

Recommended action
