IM 01C22T02-01E 8-3
8. GENERAL SPECIFICATIONS
Item Description Code
CSA Explosionproof Approval * 5
Certificate: 1010820
Explosionproof for Class I, Division 1, Groups B, C and D
Dustignitionproof for Class II/III, Division 1, Groups E, F and G
Temp. Class: T4, T5, T6 Encl Type 4x Amb. Temp.: –40 to 80
°
C (–40 to 176
°
F)
Max. Process Temp.: T4; 120
°
C (248
°
F), T5; 100
°
C (212
°
F), T6; 85
°
C (185
°
F)
Electrical connection: 1/2 NPT female *1
Process Sealing Certification
Dual seal certified by CSA to the requirement of ANSI/ISA 12.27.01
No additional sealing required. Primary seal failure annunciation : at the zero adjust-
ment screw
CF15
JF35
Canadian Standards
Association (CSA)
T0804.EPS
TIIS Certification TIIS Flameproof Approval, Ex do II C T4X * 2 * 3 * 5 * 6
PID/LM function PID control function, Link Master function * 4 LC1
Software download function* 7
Based on F OUNDATION Fieldbus Specification (FF-883)
Download class: Class1
EE
*1: Applicable for Electrical connection code 2 and 7.
*2: If cable wiring is to be used, add the YOKOGAWA-assured flameproof packing adapter.
*3: In case the ambient temperature exceeds 45
°
C, use heat-resistant cables with maximum allowable temperature of 75
°
C or above.
*4: Set as basic device when shipped.
*5: See certificate list of TIIS flameproof approval below.
T0805.EPS
With integral indicator Without integral indicator
Wetted parts material code
S
H, A
T, D
M, B
C15296
C15298
C15300
C15302
C15297
C15299
C15301
C15303
*6: TIIS (The Technology Institution of Industrial Safety) Certification is a new notation for the explosionproof approval in
Japan instead of JIS.
*7: Not applicable for Option code FS15 and KS25.
