PARTS LIST Model 800 Series Dow-Lok®
ITEM NO.
QTY
PART NO.
DESCRIPTION
1
1
276033
Shifter Ass'y
2
2
302093
Angle – "Y"
3
2
302111
Angle – "STD"
4
1
306035
SPRING - FLAT
5
2
308083
BUSHING
6
1
314007
CAM PLATE
7
1
314010
CABLE ANCHOR ("STD." DRUM ONLY)
8
1
316006
CAP BEARING
9
1
324151
CLUTCH
10
1
324318
LOCKING RING
11
1
328027
COVER - BRAKE
12
1
328122
COVER - GEAR HOUSING
13
2
330010
SHOE - DRAG BRAKE
14
1
332167
DRUM (STD)
15
1
332172
DRUM ("Y")
16
1
334189
GEAR - L.H.
17
1
334188
GEAR - R.H.
18
1
338221
HOUSING - BRAKE
19
1
338235
HOUSING - CLUTCH
20
1
338242
HOUSING - GEAR
21
1
340011
HUB - BRAKE
23
1
342053
KEY
24
1
342092
KEY
25
2
342153
KEY
26
1
352021
PLATE - RETAINER
27
1
357498
SHAFT - DRUM (STD.)
28
1
357502
SHAFT - DRUM (“Y”)
29
1
362224
SPACER
30
1
368082
WORM R.H.
31
1
368084
WORM L.H.
32
2
400007
BALL - BRAKE
33
8
400011
BALL - CLUTCH
34
2
402045
BEARING - BALL
35
1
412051
BUSHING
36
2
412052
BUSHING
37
4
414038
CAPSCREW 1/4-20NC X 3/4 LG HX HD GR5
38
4
414069
CAPSCREW 5/16-18NC X 3/4 LG HX HD
39
4
414111
CAPSCREW 5/16-18NC X 1 LG HX HD GR5
40
8
414277
CAPSCREW 3/8-16NC X 1 LG HX HD GR5 NYLOK HVY P
41
6
414282
CAPSCREW 3/8-16NC X 1-1/4 LG HX HD DR5
42
2
414399
CAPSCREW 3/8-24NF X 1-1/4 LG ALL-THRD GR5
43
8
414571
CAPSCREW 1/2-20NF X 1 LG HX HD GR5
44
1
414603
CAPSCREW 1/2-20NF X 1-3/4 LG ALL-THRD GR5
46
2
414619
CAPSCREW 1/2-13NC X 2-1/2 LG HX HD ALL-THRD ZP
47
4
414751
CAPSCREW 3/4-10NC X 1-3/4 GR5 NYLOK HVY PATCH
48
4
414777
CAPSCREW 3/4-10NC X 1-3/4 GR5
49
6
414897
CAPSCREW 3/8-16NC X 1 LG SOC HD
50
1
418067
NUT 1/2-20NF HX JAM
51
4
418163
LOCKWASHER 5/16 MED SECT PLTD
52
6
418177
LOCKWASHER 3/8 MED SECT PLTD
53
4
418184
WASHER - FLAT 3/8 ALUM
55
8
418249
LOCKWASHER 3/4 MED SECT
56
2
442192
GASKET
57
1
442194
GASKET
58
1
442195
GASKET
59
1
456008
FITTING - RELIEF
60
1
456031
FITTING - LUBE
61
2
462013
QUAD-RING
62
3
468002
REDUCER
63
2
468011
PIPE PLUG
64
4
470042
PIN - ROLL
65
4
470044
PIN - DOWEL
66
4
470056
PIN - ROLL
67
1
474030
PLATE - RETAINER
68
1
486068
SEAL - OIL
69
1
486076
THREAD SEAL
70
1
490025
RING - RETAINER
71
1
494010
SPRING
72
2
494022
SPRING - DISC
73
4
494069
SPRING
74
1
518016
THRUST WASHER
75
1
530007
DISC - BRAKE
76
2
530094
SPACER - BRAKE
77
1
416059
SETSCREW ("Y" DRUM ONLY)
78
2
456039
LUBE FITTING
