2.0 Install the FastStream Storage Controller
If you have not already completed the instructions on the Quick Start page packed with your FastStream, use the
following instructions to install the FastStream.
Unpacking the packing box; verifying
contents
• The FastStream. Note the serial number of your
FastStream unit: ________________________
• Power cord
• Brackets and screws for mounting in a 19” rack
• Ethernet
cable
• RS 232 cable
• CD which includes the Firmware, Installation
and Operation Manual, QuickNAV™ IP
discovery program and system drivers
Installing the FastStream
Exhibit 2.0-1 and Exhibit 2.0-2 on page 10 illustrate
this procedure.
1
Place the FastStream on a stable flat surface or
install it into a standard rack.
If installing into a rack:
a. Attach the brackets to both sides of the
FastStream enclosure.
b. Install the FastStream assembly
horizontally within the rack so it does not
reduce the air flow within the rack.
2 Connect the host computer to Fibre Channel
ports using SFPs and multimode fiber optic
cables.
• FastStream 5700, connect cables to FC
ports 1 and 2.
3 Connect target devices to the FastStream.
• FastStream 5300: SCSI devices
• FastStream
5500: SAS/SATA devices
• FastStream 5700: Fibre Channel devices to
ports 3 and 4
4 Power up the target devices.
5 Connect the Ethernet port to your network.
6 Connect the AC power cord from the
FastStream to the proper AC source outlet.
CAUTION CAUTION
The power source must be connected to a
protective earth ground and comply with
local electrical codes. Improper grounding
may result in an electrical shock or damage
to the unit.
If you are installing into a rack:
• Properly ground the FastStream to the rack
equipment. The earth ground connection
must be maintained.
• The power requirements plus the power
draw of the other equipment in the rack must
not overload the supply circuit and/or wiring
of the rack.
7 Use the power switch to turn on power to the
FastStream.
8 Wait up to two minutes for the FastStream
Ready LED to light indicating the FastStream
has completed its power-on self test sequence.
9 Continue to Discovering the IP address .
Discovering the IP address
Note
The FastStream is initially configured with
DHCP enabled. It is best if you have access to
a DHCP server.
1 Work from the computer attached to the
FastStream Ethernet port. From the CD
supplied with your FastStream, run the
QuickNav Utility
QuickNAV-windows.exe for
Windows or QuickNAV-Mac for Mac OS X.
2 Locate the FastStream with the serial number
recorded earlier.
3 Highlight the serial number.
4 Click Next.
If a DHCP server is available on your network,
an address is assigned automatically by the
server. Note the assigned address:
_____________________________________
If you do not have a DHCP server, get an IP
address and subnet mask from your network
administrator, type it into the area provided, and
click on
Next.
5 Click on Launch Browser.
Your browser points to the ATTO ExpressNAV
splash screen. If you use Internet Explorer as a
browser, continue on to the optional
Setting up
Internet Explorer below. If not, continue on to
Beginning initial configuration .
Setting up Internet Explorer
1 Open your browser.
