OPERATION
EAGLE 15 03/09 Operation Section 4-3
©2009 Alamo Group Inc.
OPERA
T
ION
1. Standard Equipment and Specifications
EAGLE 10 EAGLE 15
Cutting Width 126” 180”
Transport Width 88” 96”
Overall Width 133” 186”
Overall Lenth 183” 183”
Cutting Height 1-1/2” -14-1/2” 1-1/2” - 14-1/2”
Hitch 3-Pt Hitch, Pull HD Clevis
Blade Overlap 6” 6”
Blade Carrier Pan Pan
HP Required(Min.) 50 HP 50 HP
**Gearbox Rating:
Power Divider
235 HP 235 HP
Center Wing 205 HP 205 HP
Gearbox Limited Warranty 5 year 5 year
Output Shaft Diameter 2-3/8”
Blade Tip Speed:
Center 540 RPM
16,286 FPM 16,286 FPM
1000 RPM 16,380 FPM
Wings 540 RPM 16,415 FPM 16,415 FPM
1000 RPM 17,137 FPM
Cutting Capacity(Max.) 3-1/2” 3-1/2”
Driveline Size:
Main,44R or CV
CAT 5 CAT 5
Wings CAT 4 or 5 CAT 4 or 5
Driveline Limited Warranty 2 Year 2 Year
Deck Thickness 7 Ga. 7 Ga.
Side Skirts: Replaceable 1/4” x 10-1/2” 1/4”x10-1/2”
Replaceable Skid Shoes Standard Standard
Wing Flex 90° up, 22° Down 90° up, 22° Down
Safety Deflectors Standard Standard
Tractor Static Vertical Drawbar Load Rating (Min.)2100 lbs. 2100 lbs.
*Safety Deflectors are standard equipment. Single and double chain guards are available as extra equipment
at extra cost. Alamo Industrial recommends mowers be equipped with deflectors or double chain guards for all
mowing purposes. Single chain guards may be used for agriculture purposes only and are specifically not
recommended for highway, right-of-way, parks or greenbelt mowing.
**Ratings based on actual field performance.
EXTRA EQUIPMENT OPTIONAL EQUIPMENT
Open or Closed Center Three-Spool Valve Front & Rear Single or Double Chain Guards
Valve Bracket 540 or 1000 RPM
Winch and Stand CAT 4 or CAT 5 Wing Driveline
Heavy Duty Updraft Blades CAT 5 Constant Velocity Main Driveline with 1-3/4”
Auxiliary Spindle Kit Laminated, Foam-filled used Airplane tire and wheel
Used Airplane tire and wheel
15” Wheel or Implement tire and wheel
