MAINTENANCE
Gearbox Tools For Disassembly and Assembly
1.
Caulking Gun w/Silicon
2.
Impact Wrench6.
3.
Chisel 3/16" wide Blade
4.
Ball Pin Hammer
5.
Torque Wrench
6.
3/16" Punch
7.
10mm, 14mm & 17mm Socket
BE CERTAIN TO CLAMP OR SECURELY SUPPORT THE GEARBOX AND SUB-
ASSEMBLIES TO PREVENT INJURIES TO HANDS AND FEET DUE TO INADVERTENT
DROPPING OR FALLING OVER.
ALWAYS WEAR SAFETY GLASSES AND GLOVES TO PREVENT EYE AND HAND
INJURY WHEN CHISELING OR HAMMERING ON METAL COMPONENTS. HARDENED
METAL WILL CHIP UN-EXPECTEDLY.
AN ASSEMBLED GEARBOX IS QUITE HEAVY. USE A HOIST OR GET HELP TO
HANDLE THEM SAFELY. LIFT CAREFULLY AND PROPERLY USING YOUR LEGS TO
LIFT - NOT YOUR BACK.
NOTICE: REFER TO OPERATOR’S MANUAL FOR INSTRUCTIONS FOR PROPER RE-ASSEMBLY ONTO
THE CUTTER DECK. TIGHTEN CORRECTLY.
