MAINTENANCE
EAGLE 15 03/09 Maintenance Section 5-25
©2009 Alamo Group Inc.
MAINTENANCE
loosened. Repeat this process until the Shaft no longer becomes loose in the assembly. Unscrew the Nut a
small amount and again tap each end of Shaft while holding the Hub. Repeat this process until a rolling torque
of 10 to 12 inch pounds is reached on the Shaft.
STEP 4
Apply a small amount of Silicon sealer to the bore of the Hub Cap and to the outside diameter of the Seal.
FIGURE Mnt-R-0063. Drive the Seal into the base of the Hub Cap. FIGURE Mnt-R-0063-Mnt-R-0067
