7.3.7 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 10) shows the hardware health status.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU temperature :+56 C
System temperature :+55 C
Environment temperature :+25 C
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
o Environment Temperature
7.3.8 S e ria l P o rt Co n s o le Re d ire c tio n
The Serial Port Console Redirection menu (BIOS Menu 11) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
