AFL2-08A-N26
P a g e 46
Co n n e c to r Typ e La b e l
K type connector 2-pin wafer K_TYPE1, K_TYPE2
LCD inverter connector 5-pin wafer INVERTER1
LCD LVDS connector 20-pin wafer JR1
LED connector 14-pin wafer LEDCN1
LPT connector 20-pin wafer LPT_DB1
Micro SD connector 5-pin wafer MICRO_SD1
Mini USB connector 4-pin wafer MINI_USB1
Microphone connector 4-pin wafer WEBCAM_DMIC1
PCIe mini card slot PCIe mini card slot MINI_PCIE1, MINI_PCIE2
Power button connector 2-pin wafer PW_BT1
RFID USB connector 4-pin wafer RFID1
Speaker connector 4-pin wafer AMP_SPKR1
Touch panel connector 9-pin wafer TS1
Touch panel connector 4-pin wafer CAP_TS1
VGA connector 10-pin header VGA1
Webcam connector 4-pin wafer CAMERA1
AT/ATX mode select switch AT_SEL1
Clear CMOS switch CLR_COMS1
Reset button button RST1
Table 5-1: Peripheral Interface Connectors
5.2.1 Au d io Co n n e c to r (AUDIO1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 LINE_OUTR 2 LMIC1-L
3 AMP_INR 4 LMIC1-R
5 LINE_OUTL 6 FRONT_JD
7 FRONT_JD 8 MIC1_JD
