AFL2-08A-N26
P a g e 6
The corresponding Function Keys are located under the bottom right hand corner of the
LCD screen (Figure 1-4).
Figure 1-4: Function Keys
The Function Keys are described in Table 1-3:
Ke y Co m b in a tio n Fu n c tio n Ke y De s c rip tio n
Fn + LCD On/Off RFID Enable/Disable
Fn + Audio Volume Down Audio Mute
Fn + Brightness Down Mini USB / Micro SD Enable/Disable
Fn + Brightness Up Power On/Off
Note: To power on the system, hold down the Fn +
Brightness Up buttons for 3 seconds. To power down the
system, hold down the FN + Brightness Up buttons for six
seconds.
Fn: The function key can maintain for 2sec.
Table 1-3: Function Key Descriptions
1.2.2 Re a r P a n e l
The rear panel provides access to retention screw holes that support the wall mounting.
Refer to Figure 1-5.
