AFL2-08A-N26
P a g e 50
Table 5-13: LED Connector Pinouts (LEDCN1)
5.2.13 LP T Co n n e c to r (LP T_DB1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 EC_KSI0 2 EC_KSO0
3 EC_KSO1 4 EC_KSO2
5 EC_KSO3 6 EC_KSO4
7 EC_KSO5 8 EC_KSO6
9 EC_KSO7 10 EC_KSO8
11 EC_KSO9 12 EC_KSO10
13 EC_KSO12 14 EC_KSI1
15 EC_KSO11 16 EC_KSI2
17 EC_KSI3 18 GND
19 GND 20 GND
Table 5-14: LPT Connector Pinouts ( LPT_DB1)
5.2.14 Mic ro S D Co n n e c to r (MICRO_S D1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC_MSD 2 DATA3_N
3 DATA3_P 4 GND
5 VCC3
Table 5-15: Micro SD Connector Pinouts (MICRO_SD1)
5.2.15 Min i US B Co n n e c to r (MINI_US B1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 VCC_NIMIUSB 2 DATA2_N
3 DATA2_P 4 GND
Table 5-16: Mini USB Connector Pinouts (MINI_USB1)
