5.2.10 LCD In ve rte r Co n n e c to r (INVERTER1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 BRIGHTNESS 2 DATA7_N
3 BKL_POWER 4 GND
5 ENABKL
Table 5-11: LCD Inverter Connector Pinouts (INVERTER1)
5.2.11 LCD LVDS connector (J R1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 LVDSA_DATA0_R 4 LVDSA_DATA#0_R
5 LVDSA_DATA1_R 6 LVDSA_DATA#1_R
7 LVDSA_DATA2_R 8 LVDSA_DATA#2_R
9 LVDSA_CLK_R 10 LVDSA_CLK#_R
11 LVDSA_DATA3_R 12 LVDSA_DATA#3_R
13 GND 14 GND
15 NC 16 NC
17 VCC3 18 VCC_LCD
19 VCC_LCD 20 VCC_LCD
Table 5-12: LCD LVDS connector Pinouts (JR1)
5.2.12 LED Co n n e c to r (LEDCN1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 CPU_LEDR# 2 CPU_LEDB#
3 AT_LED# 4 ATX_LED#
5 PWR_LED# 6 PWR_YLED#
7 AD_LED# 8 WIFI_LED#
9 RF_LED# 10 BT_LED#
11 VCC3A_EC 12 VCC3
13 GND 14 GND
