AFL2-08A-N26
P a g e 9
Contrast Ratio 500:1
LCD Color 16.2 M
Pixel Pitch (H x V) (mm) 0.2025(H) x 0.2025(V)
Viewing Angle (H-V) 140°(H) / 130°(V)
Backlight MTBF (hr) 30000 hrs
Touch Screen 5-wire resistive type touch screen
CPU Intel® Atom™ N2600 dual core 1.6 GHz CPU
Chipset Intel® NM10
Ethernet Realtek RTL8111E PCIe GbE controller support ASF2.0
Memory Support one 800 MHz 204-pin DDR3 SO-DIMM slot (max. 2G)
pre-installed with 2GB
Expansion 1 x PCIe x1 for Wi-Fi
SSD PCIe mSATA
Audio AMP 0.8 W + 0.8 W (built-in stereo speakers)
Microphone Digital Microphone
RFID Reader EM 125 KHz or MIFARE 13.56 MHz card reader (optional)
MSR card reader MSR card reader (optional)
Wireless 1 x Wireless LAN 802.11 b/g/n 2T2R module
(internal PCIe Mini card interface)
(Optional, internal USB interface, Bluetooth V2.0+EDR)
OSD Function LCD on / off, brightness up / down, volume up / down, Hot Key
Construction Material PC+ ABS plastic front frame
Mounting Wall, Panel, Stand and VESA 75 mm x 75mm
Front Panel Color Black
Net Weight 1.43 kg / 2.2 kg
Dimensions (W x H x D) (mm) 215 (W) x 188 (H) x 46 (D)
Operation Temperature -20ºC ~ 40ºC
Storage Temperature -20ºC ~ 60ºC
Humidity 10% to 95% (non-condensing)
IP level Front panel IP 64
Safety&EMC CE / FCC
Power Supply 36W power adapter
Input: 90VAC~264VAC, 50/60 Hz, Output: 12VDC
Power Requirement 9V ~ 36V DC
