IBX-530B-270 Embedded System
Page 3
Optional 802.11b/g/n wireless LAN module
Wall mount supported
1.2 IBX-530B-N270 Model Variations
There two models of the IBX-530B-N270 series embedded system. Both models have a
preinstalled 1.0 GB DDR2 memory module preinstalled. The model variations are listed in
Table 1-1 below.
Model CPU Memory Wireless LAN
IBX-530B-R21/N270/1GB 1.6 GHz Intel® Atom™ 1.0 GB DDR2 No
IBX-530BW-R21/N270/1GB 1.6 GHz Intel® Atom™ 1.0 GB DDR2 Yes
Table 1-1: Model Variations
1.3 Technical Specifications
The specifications for the Intel based embedded systems are listed below.
IBX-530B-N270
CPU 1.6 GHz Intel® Atom™ N270 CPU
System Chipset Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7M
System Memory
1.0 GB DDR2 SDRAM SO-DIMM preinstalled
Ethernet
Dual Realtek RTL8111CP PCIe GbE controllers
Display VGA integrated in Intel® 945GSE
USB Four USB 2.0 ports supported
Serial Port One RS-232 port
One RS-232/422/485 port
Audio One audio speaker-out connector
Storage One external SATA connector
One CompactFlash® Type I or Type II card supported
Wireless 802.11b/g/n wireless module (IBX-530BW-R21/N270 only)
