IBX-530B-270 Embedded System
Page 109
17 A3 42 WAIT
18 A2 43 INPACK
19 A1 44 REG
20 A0 45 BVD2
21 D0 46 BVD1
22 D1 47 D8
23 D2 48 D9
24 IOCS16 49 D10
25 CD2 50 GND
Table e B-2: CFII Socket Pinouts (CF1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 DCD1 2 RX1
3 TX1 4 DTR1
5 GND 6 DSR1
7 RTS1 8 CTS1
9 COM_RI1 10 GND
Table e B-3: COM1 Connector Pinouts (COM1, D-SUB)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 NDCDB 2 NRXDB
3 NTX3 4 NDTR3
5 GND 6 NDSRB
7 NRTSB 8 NCTS3
9 COM_RI3 10 GND
Table e B-4: COM3 Connector Pinouts (COM3, D-SUB)
Pin No. Description
1 GND
2 GND
3 VCC12_IN
Table e B-5: 12V DC Power Connector Pinouts (CN5)
Pin No. Description Pin No. Description
1 DACR_RED 2 SPD2
3 DACG_GREEN 4 SPCLK2
5 DACB_BLUE 6 V_GND
