ECW-281B/B2-D525 Embedded System
Page 65
5.3.6 H/W Monitor
The H/W Monitor menu (
6
BIOS Menu 9 ) shows the operating temperature, fan speeds and
system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+53 C
Accuracy:1.(-5~+10)degree around 100 degree
2.(-10~+15)degree around 50 degree
SYS Temperature
:+37 C
CPU FAN Speed :N/A
SYS FAN Speed :N/A
VCC3C :+3.312 V
V_core :+1.160 V
V1_05V :+1.040 V
VCC3V :+3.288 V
Vcc :+5.003 V
VSB3V :+3.328 V
VBAT :+3.216 V
CPU Smart Fan control [Auto Mode]
Temperature Bound 1 60
Temperature Bound 2 50
Temperature Bound 3 40
Temperature Bound 4 30
SYS Smart Fan control [Auto Mode]
Temperature Bound 1 60
Temperature Bound 2 50
Temperature Bound 3 40
Temperature Bound 4 30
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
Î PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ System Temperatures:
o CPU Temperature
o System Temperature
ƒ Fan Speeds:
