ECW-281B/B2-D525 Embedded System
Page 6
1.4 Power Module Specifications (Optional)
A DC-to-DC power module is preinstalled in the WD series model to provide 9 V~36 V
power input. The specifications for the IDD-936260A are shown in
655
Table 1-3 .
Model Name: IDD-936260A
Input 9 V DC~36 V DC
Output:
12V 3 A (Max.)
5V 10 A (Max.)
5VSB 0.5 A (Max.)
Max. Total Output: 60 W
Performance Characteristics:
Noise & Ripple: < 240 mV
Line Regulation: < 20 mV
Load Regulation <60 mV
Efficiency: Up to 90%
Dimensions: 40 mm x 100 mm
Weight: 58 g
Operating Temperature: -40°C~85°C
Table 1-3: DC-to-DC Power Module Specifications
