5.4.1 NorthBridge Configuration
Use the NorthBridge Configuration menu (BIOS Menu 15) to configure the Northbridge
chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
NorthBridge Configuration
Memory Information
Memory Frequency
1067 Mhz
Total Memory 1024 MB (DDR3)
DIMM#1
1024 MB (DDR3)
DIMM#2 Not Present
NB PCIe Configuration
PEG0
Not Present
VT-d
[Disabled]
Primary Display [Auto]
> Graphics Configuration
Check to enable VT-d
function on MCH.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15:Northbridge Configuration
Î VT-d [Disabled]
Use the VT-d option to enable or disable VT-d support.
Î
Disabled D EFAULT Disables VT-d support.
Î
Enabled Enables VT-d support.
Î Primary Display [Auto]
Use the Primary Display option to select the primary display controller the system uses.
The following options are available:
ƒ Auto D EFAULT
ƒ IGFX
ƒ PCI
