IEI Integration NANO-HM651 - Manual (Page 21)

NANO-HM651 EPIC SBC
Page 7
Specification NANO-HM651
USB Ports Two external USB 2.0 ports
Two external USB 3.0 ports (via ASMedia ASM1042 USB 3.0 extended
host controller)
Keyboard/Mouse One keyboard and mouse connector via internal 6-pin header
SMBus One 4-pin wafer connector
Fan One 4-pin wafer CPU fan connector
One 3-pin wafer system fan connector
Storage
Serial ATA Two SATA 6Gb/s ports with 5V power connectors
Environmental and Power Specifications
Power Supply 12 V, AT/ATX power support
Power Consumption [email protected] (Intel® Celeron® with 4GB 1333MHz DDR3 memory)
Operating Temperature -10
°C~60°C
Storage Temperature -20
°C~70°C
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions (LxW) 115 mm x 165 mm
Weight GW/NW 850g/350g
Table 1-1: Technical Specifications
