NANO-HM651 EPIC SBC
Page 15
3.1.3 External Interface Panel Connectors
6
Table 3-2 lists the rear panel connectors on the NANO-HM651. Detailed descriptions of
these connectors can be found in Section
6
3.3 on page
6
32.
Connector Type Label
Ethernet connectors RJ-45 LAN1, LAN2
HDMI connectors HDMI HDMI1, HDMI2
USB 2.0 ports USB port USB_CON2
USB 3.0 ports USB port USB_CON3
VGA port connector 15-pin female VGA1
Table 3-2: Rear Panel Connectors
3.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the CPU card and are only accessible when
the CPU card is outside of the chassis. This section has complete descriptions of all the
internal, peripheral connectors on the NANO-HM651.
3.2.1 Audio Connector
CN Label: AUDIO1
CN Type: 10-pin header (2x5)
CN Location: See Figure 3-2
CN Pinouts: See Table 3-3
The 10-pin audio connector is connected to external audio devices including speakers and
microphones for the input and output of audio signals to and from the system.
