5.4.2 Southbridge Configuration
Use the Southbridge Configuration menu (BIOS Menu 17) to configure the Southbridge
chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
SouthBridge Configuration
Auto Power Button Status
[OFF]
Azalia [Enabled]
Power Saving Function
[Disabled]
Restore AC Power Loss [Last State]
Control Detection of the
Azalia device.
Disabled=Azalia will be
unconditionally
disabled
Enabled=Azalia will be
unconditionally Enabled
Auto=Azalia will be
enabled if present,
disabled otherwise.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 17: Southbridge Chipset Configuration
Î Azalia [Enabled]
Use the Azalia option to enable or disable the High Definition Audio controller.
Î
Disabled The onboard High Definition Audio controller is disabled
