NANO-HM651 EPIC SBC
Page 6
1.5 Technical Specifications
NANO-HM651 technical specifications are listed in table below.
Specification NANO-HM651
Form Factor EPIC
CPU Options Intel® Celeron® dual-core 847E processor 1.1GHz
System Chipset Intel® HM65
Graphics Engine Intel® HD Graphics Gen 6 support for DX10.1 and OpenGL 3.0
Full MPEG2, VC1, AVC Decode
Memory Two 204-pin SO-DIMM sockets support two 1333/1066 MHz
dual-channel DDR3 SDRAM SO-DIMM (system max. 8 GB)
Ethernet Controller Two Realtek RTL8111E PCIe GbE controllers with ASF2.0 support
BIOS UEFI BIOS
Super I/O Fintek F81866
Digital I/O 8-bit digital I/O (4-bit input, 4-bit output)
Audio Codec Realtek ALC662 HD Audio codec
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansion
PCIe One PCIe Mini slot with mSATA support
I/O Interface Connectors
Display VGA and LVDS integrated in Intel® HM65:
- One VGA port (2048 x 1536@75Hz)
- 24-bit dual-channel LVDS (up to 1920 x 1200@60Hz)
Two HDMI ports (up to 1920 x 1200@60Hz)
Ethernet Two RJ-45 GbE ports
Audio One internal audio connector supports line-out, line-in and mic-in
Serial Ports Two RS-232 serial ports via internal 10-pin header
One RS-422/485 serial ports via internal 4-pin wafer
