Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
SYS Smart Fan control [Auto by PWM]
Target Temp Sensor [CPU Temperature]
Temperature Bound 1 60
Temperature Bound 2 50
Temperature Bound 3 40
Temperature Bound 4 30
Segment 1 Speed (PWM) 100
Segment 2 Speed (PWM) 85
Segment 3 Speed (PWM) 70
Segment 4 Speed (PWM) 60
Segment 5 Speed (PWM) 50
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 13: SYS Fan 1 Configuration
 CPU Smart Fan control [Auto by PWM]
Use the CPU Smart Fan control option to configure the CPU Smart Fan.

Auto by RPM The fan adjusts its speed using Auto by RPM
settings

Auto by PWM D EFAULT The fan adjusts its speed using Auto by PWM
settings

Manual by
RPM
The fan spins at the speed set in Manual by RPM
settings

Manual by
PWM
The fan spins at the speed set in Manual by PWM
settings
 Target Temp. Sensor [CPU Temperature]
Use the Target Temp. Sensor option to set the target CPU temperature.

CPU
Temperature
D EFAULT Sets the target temperature sensor to the CPU
temperature.
