5.3.7 H/W Monitor
The H/W Monitor menu (BIOS Menu 11) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+50 C
SYS Temperature :+44 C
CPU FAN Speed :2189 RPM
SYS FAN Speed :N/A
VCC3V :+3.344 V
V_core :+1.248 V
+1.05V :+1.064 V
VDDR :+1.616 V
VSB3V :+3.424 V
VBAT :+2.816 V
5VSB :+4.968 V
> CPU Fan Configuration
> SYS Fan 1 Configuration
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 11: Hardware Health Configuration
 PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speeds:
o CPU Fan Speed
o System Fan Speed
 Voltages:
o VCC3V
o Vcore
o +1.05V
