KINO-DH610
Page 7
Specification KINO-DH610
Display Ports One VGA integrated in Intel® H61
One DVI-D integrated in Intel® H61
One HDMI integrated in Intel® H61
Ethernet Two RJ-45 GbE ports
Keyboard/Mouse One internal keyboard and mouse connector via 6-pin wafer
TPM One 20-pin header
Fan One 4-pin CPU fan connector
One 3-pin system fan connector
Serial Ports One external RS-232 serial port via DB-9 male connector
One RS-232 and one RS-422/485 via internal 14-pin header
USB Ports Four external USB 2.0 ports by rear IO
Six internal USB 2.0 ports via three 8-pin headers
Storage
Serial ATA Four SATA 3Gb/s connectors
Environmental and Power Specifications
Power Supply Maximum input voltage range: 9 V ~ 28 V
Recommended operating input voltage range: 12 V ~ 24 V
Power Connector One external DC jack (4-pin DIN)
One internal 4-pin power connector
Power Consumption [email protected] (2.2 GHz Intel® G620T with two 1066 MHz 2 GB
DDR3 running 3DMark06 burn in)
[email protected] (2.8 GHz Intel® Core™ i7-2600S with two 1066
MHz 2 GB DDR3 running 3DMark06 burn in)
Operating Temperature -10ºC ~ 60ºC
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 170 mm x 170 mm
