PCIE-G41A2 PICMG 1.3 CPU card

Page 26

Pin Description Pin Description

1 RESET#

2 GND

3

DATA 7

4

DATA 8

5

DATA 6

6

DATA 9

7

DATA 5

8

DATA 10

9

DATA 4

10

DATA 11

11

DATA 3

12

DATA 12

13

DATA 2

14

DATA 13

15

DATA 1

16

DATA 14

17

DATA 0

18

DATA 15

19 GND

20 N/C

21 IDE

DRQ

22 GND

23 IOW#

24 GND

25 IOR#

26 GND

27

IDE CHRDY

28

BALE – DEFAULT

29 IDE

DACK

30 GND

31 INTERRUPT 32 N/C

33 SA1

34 PDIAG#

35 SA0

36 SA2

37

HDC CS0#

38

HDC CS1#

39 HDD

ACTIVE#

40 GND

Table 3-12: Parallel ATA (IDE) Connector Pinouts

3.2.12 Parallel Port Connector

CN Label:

LPT1

CN Type:

26-pin box header

CN Location:

See Figure 3-13

CN Pinouts:

See Table 3-13

The parallel port connector connects to a parallel port connector interface or some other

parallel port device such as a printer.
