2 Warner Electric • 800-825-9050 P-212 • 819-0078
Contents
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Instructions . . . . . . . . . . . . . . . . . . 4
Replacing Worn Parts . . . . . . . . . . . . . . . . . . . 4
Burnishing and Maintenance . . . . . . . . . . . . . . 6
Electrical Data Coil Ratings . . . . . . . . . . . . . . . 8
Exploded Views and Parts List
EP-170, 250, 400 . . . . . . . . . . . . . . . . . . . . 9
EP-500 . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
EP-825 . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
EP-1000 . . . . . . . . . . . . . . . . . . . . . . . . . . 16
EP-1525, 1525 HT. . . . . . . . . . . . . . . . . . . 17
Warranty . . . . . . . . . . . . . . . . . . . . . . Back Page
Failure to follow these
instructions may result in product damage,
equipment damage, and serious or fatal
injury to personnel.
Base Mounted Clutch/Brake
Combinations in a Rugged Housing
Meets electrical codes
UL Listed or CSA Certified.
Pre-packaged
Over 20 major compo-
nents have been pre-
engineered and
pre-assembled in a
typical Electro Pack.
Ready-to-go, straight
from the box.
Brake output shaft
Foot mounted
Bolt-it-down and wire-it-up. Allows for
quick replacement/reduced downtime.
Maintenance free
Never needs lubrication.
Self-adjusting for wear of
clutch-brake friction faces.
Consistent performance.
Clutch input shaft
Heavy duty bearings
Properly aligned for
maximum performance.
