Setting the Temperature Units of Measure
When performing tests, you can provide the Device Under Test (D.U.T.) temperature and the
IRM-5000P will automatically calculate the equivalent resistance values at 40
°C and 20°C. You
can select the preferred units of measure for entering the D.U.T. temperature by using the
steps below:
a. Start from the “START-UP” menu:
Press the
[2]
key (UTILITIES).
b. The following screen will be displayed:
Press the
[3]
key (SETUP).
c. The following screen will be displayed:
Press the
[5]
key (
°C/°F
).
d. The following screen will be displayed:
Press the
[1]
key (
°
C) or the
[2]
key (
°
F) to select the corresponding units of measure.
The D.U.T. temperature units of measure will be set and you will be returned to the
“START-UP” menu.
1.
°C
2.
°F
