REV 2 IRM-5000P USER’S MANUAL

31

Press the

[1]

key (YES) to print the test report (See Figure 10 for a sample test report

printout).

i. The test report will be printed on the built-in thermal printer, and then the following

screen will be displayed:

Press the

[1]

key (YES).

j. The following screen will be displayed:

Press any key to continue.

k. The following screen will be displayed:

Press the

[2]

key (NO). You will be returned to the “START-UP” menu.

NOTE

Please see section 3.2.3 for instructions on how to print test results graphs.

REPEAT TEST?

1.YES 2.NO


TERMINAL VTG: 1 V

TEST NUMBER 9
HAS BEEN SAVED!

TERMINAL VTG: 1 V

SAVE TEST?

1.YES 2.NO

TERMINAL VTG: 1 V

PRINT REPORT?

1.YES 2.NO

TERMINAL VTG: 1 V
