IRM-5000P USER’S MANUAL REV 2
12
c. The following screen will be displayed:
Press the [1] key (TEST ID).
d. The following screen will be displayed:
Type the company name using the alpha-numeric keypad.
When pressing a key, the corresponding number on the key will be displayed first.
Pressing the key again will display the first letter on the key. Pressing the key again will
display the second letter on the key. For example, to type the letter “A”, you must press
the
[2]
key twice. To erase the character at the cursor position, press the
[CLEAR]
key.
Press the
[PAPER ∧ Contrast]
key to move to the next character. Press the
[PAPER
∨ Contrast] key to move to the previous character. Press the [ENTER] key when you
are done typing the company name.
e. The following screen will be displayed:
Type the location name using the alpha-numeric keypad and then press the [ENTER]
key.
f. The following screen will be displayed:
Type the test description using the alpha-numeric keypad and then press the [ENTER]
key.
g. The following screen will be displayed:
TEST DESCRIPTION
_
ENTER to Confirm
TERMINAL VTG: 1 V
LOCATION
_
ENTER to Confirm
TERMINAL VTG: 1 V
COMPANY
_
ENTER to Confirm
TERMINAL VTG: 1 V
1.TEST ID 2.CLOCK
3.COMP INT 4.50/60Hz
5.
°C/°F
TERMINAL VTG: 1 V
