3.2.3. Printing a Test Record from the Working Memory

After performing a test, the results are stored in the IRM-5000P’s working memory. The
tabulated results, resistance plot, and current plot can then be printed. Also, if a record is
restored from the unit’s Flash EEPROM to the working memory, the test results can be printed
on the thermal printer. Use the steps below to print a test record from the working memory:

a. Either perform a test or restore a test record from the Flash EEPROM. Then start from

the “START-UP” menu:

Press the

[2]

key (UTILITIES).

b. The following screen will be displayed:

Press the

[1]

key (PRINT).

c. The following screen will be displayed:

1. PLOT R

Press the

[1]

key (PLOT R) to print the resistance versus time graph. The graph

will be printed on the thermal printer and you will be returned to the “START-
UP” menu.

2. PLOT I

Press the

[2]

key (PLOT I) to print the current versus time graph. The graph will

be printed on the thermal printer and you will be returned to the “START-UP”
menu.

3. PLOT R,I

Press the

[3]

key (PLOT R,I) to print both the resistance versus time graph and

the current versus time graph. The graphs will be printed on the thermal printer
and you will be returned to the “START-UP” menu.

1.PLOT R 2.PLOT I
3.PLOT R,I 4.SUMMARY

TERMINAL VTG: 1 V

1.PRINT 2.SAVE/RES

3.SETUP

TERMINAL VTG: 1 V

RUN TEST 05/05/10

2. UTILITIES 15:15:15
