g. The following screen will be displayed while the test is being performed:
The LCD screen will be dynamically updated displaying the remaining time along with
the resistance, current, and test voltage values. When the test is completed, the results
will be displayed as shown:
Press any key to continue.
h. The following screen will be displayed:
Press the
[1]
key (YES) to print the test report (See Figure 12 for a sample test report
printout).
i. The test report will be printed on the built-in thermal printer, and then the following
screen will be displayed:
Press the [1] key (YES).
j. The following screen will be displayed:
Press any key to continue.
TEST NUMBER 10
HAS BEEN SAVED!
TERMINAL VTG: 1 V
SAVE TEST?
1.YES 2.NO
TERMINAL VTG: 1 V
PRINT REPORT?
1.YES 2.NO
TERMINAL VTG: 1 V
R= 2.179M DD=5.8
200V 3.85uF 30:00
TERMINAL VTG: 1 V
Bat: Time: 29:57
Resistance: 1.802 M
Current: 0.105 mA
TEST VOLTAGE: 200 V
