IRM-5000P USER’S MANUAL
REV 2
24
2. NO
Press the
[2]
key (NO) if you do not want to enter the Device Under Test (D.U.T.)
temperature. Continue to step f.
f. The following screen will be displayed:
1. YES
Press the
[1]
key (YES) to print the resistance readings on the IRM-5000P’s built-
in thermal printer. If this option is selected, the resistance values will be printed
at every second, starting at 10 seconds. Continue to step g.
2. NO
Press the
[2]
key (NO) if you do not want to print the resistance readings.
Continue to step g.
g. The following screen will be displayed:
The IRM-5000P will perform self-calibration, and then the following screen will be
displayed:
Press the
[ENTER]
key to start the test.
h. The following screen will be displayed while the test is being performed:
Bat:
Time: 09:43
Resistance: 2.517 M
Current: 98.16 uA
TEST VOLTAGE: 350 V
“ENTER” TO START!
PI 350V 10Min
TERMINAL VTG: 1 V
CALIBRATING
PLEASE WAIT 25
TERMINAL VTG: 1 V
PRINT DURING TEST?
1. YES 2. NO
TERMINAL VTG: 1 V
