EZCT-2000B USER’S MANUAL REV 1
88
4.0 CHANGING SETUP PARAMETERS
4.1 Setting the Knee Point Marker
Use the steps below to change the knee point marker for the excitation graph:
a. Start from the “START-UP” menu:
Press the [2] key (SETUP).
b. The following screen will be displayed:
Press the
[6]
key (NEXT PAGE).
c. The following screen will be displayed:
Press the
[3]
key (KNEE POINT MARKER)
1. SET TIME
2. buried ct in delta
3. knee point marker
4. print raw data
1. RECORD ID
2. PRINT RECORD
3. RECORD DIRECTORY
4. SAVE/RESTORE RECORD
5. ERASE RECORD
6. NEXT PAGE
1. RUN TEST 06/17/09
2. SETUP 02:16:58
3. TEST PLANS
4. DIAGNOSTICS
5. CURRENT SOURCE
