EZCT-2000B USER’S MANUAL
REV 1
32
g. The following screen will be displayed:
NOTE
The “HIGH VOLTAGE PRESENT” light will be illuminated to indicate that high
voltage is present.
The following screen will be displayed momentarily:
Then the following screen will be displayed:
When the test is completed, the test results will be displayed temporarily:
CABLES ENERGIZED!
BURDEN TEST RESULTS
2.983 VA
COS
ϕ
= 0.92
CABLES ENERGIZED!
I=0.0018 AMPS
V= 1.3 VAC
CABLES ENERGIZED!
PLEASE WAIT...
CABLES ENERGIZED!
I=0.0016 AMPS
V= 1.2 VAC
