EZCT-2000B USER’S MANUAL REV 1
20
e. If the selected test included an excitation test, the following screen will be displayed:
Select the maximum test current for the excitation test by pressing the corresponding
key (
[1] - [6] ).
f. If the selected test included a ratio test, the following screen will be displayed:
1. YES
Press the [1] key if you would like to enter the CT nameplate values. The
following screen will be displayed:
Type the first number using the keypad.
NOTE
You can press the
[CLEAR]
key to restart a field entry if necessary.
ENTER PLATE RATIO:
0 :
XFMR NAME PLATE RAT.
1.
YES
2. NO
SET TEST CURRENT:
1.
0.2A
2. 0.5A
3. 1A
4. 2A
5. 5A
6. 10A
