REV 1 EZCT-2000B USER’S MANUAL
53
3.4.5. Printing a Directory of Test Records Stored in a USB Flash Drive
You can print a directory of all the test records stored in a USB Flash drive using the steps
below:
a. Make sure the USB Flash drive is inserted in the EZCT-2000B’s USB Flash drive port
(“USB MEM” port). Then start from the “START-UP” menu:
Press the [2] key (SETUP).
b. The following screen will be displayed:
Press the [3] key (RECORD DIRECTORY).
c. The following screen will be displayed:
Press the
[2]
key (THUMB DRIVE DIR).
d. The following screen will be displayed while the directory is printed:
When printing is finished, you will be returned to the “START-UP” menu. A sample
directory printout is shown in Figure 14.
PRINTING DIRECTORY
1. INTERNAL DIRECTORY
2. THUMB DRIVE DIR
1. RECORD ID
2. PRINT RECORD
3. RECORD DIRECTORY
4. SAVE/RESTORE RECORD
5. ERASE RECORD
6. NEXT PAGE
1. RUN TEST 06/17/09
2. SETUP 10:14:25
3. TEST PLANS
4. DIAGNOSTICS
5. CURRENT SOURCE
