c. The following screen will be displayed:
Press the [7] key (INSULATION TST ONLY)
d. The following screen will be displayed:
Use the alpha-numeric keypad to enter a test note and then press the [ENTER] key.
e. The following screen will be displayed:
Select the test voltage by pressing either the
[1]
key (500V) or the
[2]
key (1000V).
f. The following screen will be displayed:
Connect the insulation resistance cables and then press the
[START]
key.
TEST 1 PARAMETERS
500V INS RES TEST
CONNECT INS REST TEST
CABLES NOW.
"START" TO BEGIN
INS RES TEST VOLTAGE:
1.
500V
2. 1000V
ENTER TEST 1 NOTE:
_
↑↓
to position
"ENTER" TO ACCEPT
1. Res, excit & ratio
2. excitation & ratio
3. excitation only
4. ratio only
5. resistance & excit
6. burden test only
7. insulation tst only
