REV 1 EZCT-2000B USER’S MANUAL
23
m. If the selected test included a resistance test, the following screen will be displayed
momentarily:
The following screen will then be displayed:
NOTE
The “HIGH VOLTAGE PRESENT” light will be illuminated to indicate that high
voltage is present.
n. If the selected test included a ratio test, the following screen will be displayed
momentarily:
The following screen will then be displayed:
RATIO TEST
V
x
= 99.5 V
H
= 0.497
I=0.0402 RAT=+199.88
CABLES ENERGIZED!
300V
1.0A x1-x2
I= 0.0004 AMPS
V= 34.2 VAC
CABLES ENERGIZED!
300V
1.0A x1-x2
RESISTANCE = 215.1
Ω
CABLES ENERGIZED!
300V
1.0A x1-x2
DC RESISTANCE TEST
