4.2 Performing a Transducer Self-Test
You can check the transducer electronics by connecting the transducer to the CT-7000 S2 and
running a transducer self-test using the instructions below:
a. Start from the “START-UP” menu:
Press the
[4]
key (DIAGNOSTICS).
b. The following screen will be displayed:
Press the [3] key (TEST TRANSDUCER).
c. The following screen will be displayed:
Move the transducer slider to a known distance and observe the display.
d. The screen will be updated with the new transducer position information:
If the transducer was moved 5 inches, the screen should display 5.00 IN. You can
continue to move the transducer slider and observe the screen values to make sure they
are correct. Press the
[STOP] key to end the test and return to the “START-UP” menu.
TRANSDUCER TEST:
1= 5.00 IN / 360.0
x
2= 0.00 IN / 000.0 x
2= 0.00 IN / 000.0 x
TRANSDUCER TEST:
1= 0.00 IN / 000.0
x
2= 0.00 IN / 000.0 x
2= 0.00 IN / 000.0 x
1. SLOW CLOSE TEST
2. CHECK HOOKUP
3. TEST TRANSDUCER
4. NEXT PAGE
1. TIME BRKR 02/14/11
2. GET RSLT 09:35:45
3. SETUP
4. DIAGNOSTICS
