CT-7000 S2 USER’S MANUAL

REV 2

Loading a Resistor Type Transducer Setup

Follow the steps below to load a resistor type transducer setup:

a. Start from the “START-UP” menu:

Press the

[3]

key (SETUP).

b. The following screen will be displayed:

Press the

[2]

key (MEASUREMENT UNITS).

c. The following screen will be displayed:

NOTE

Option 4 (RES ENC) will be available only if the CT-7000 S2 unit has the optional
R1 channel installed.

Press the

[4]

key (RES ENC).

d. The following screen will be displayed:

Press the

[2]

key (LOAD SETUP).

e. The following screen will be displayed:

Type the setup number to load using the numeric keypad.

ENTER SETUP NUMBER
TO LOAD (1-9):

RESISTIVE ENCODER
1. CREATE NEW SETUP

2. LOAD SETUP

3. PRINT SETUP DIR

SELECT UNITS:

1. ENGLISH

2. METRIC

3. ROT ENC 4.RES ENC

1. ANALYSIS POINTS

2. MEASUREMENT UNITS

3. SAVE / RESTORE

4. NEXT PAGE

1. TIME BRKR 02/07/11

2. GET RSLT 14:04:05

3. SETUP

4. DIAGNOSTICS
