REV 2 CT-7000 S2 USER’S MANUAL

3.1.17. Configuring the Digital Rotary Transducer Settings

A rotary transducer requires the user to enter the defined linear distance in millimeters or
inches per one degree of rotary motion. Follow the steps below to configure the settings for a
digital rotary transducer:

a. Start from the “START-UP” menu:

Press the

[3]

key (SETUP).

b. The following screen will be displayed:

Press the

[2]

key (MEASUREMENT UNITS).

c. The following screen will be displayed:

Press the

[3]

key (ROTARY ENCODER).

d. The following screen will be displayed:

1. ENGLISH (In./deg)

Press the

[1]

key to enter the rotary encoder linear distance per degree using

English units. The following screen will be displayed:

INCHES/DEGREE

5.535 In/Deg

ROTARY ENCODER:
1. ENGLISH (In./deg)

2. METRIC (MM/deg)

SELECT UNITS
1. ENGLISH

2. METRIC

3. ROTARY ENCODER

1. ANALYSIS POINTS

2. MEASUREMENT UNITS

3. SAVE / RESTORE

4. NEXT PAGE

1. TIME BRKR 02/04/11

2. GET RSLT 09:04:05

3. SETUP

4. DIAGNOSTICS
