REV 2 CT-7000 S2 USER’S MANUAL
68
3.3.2. Printing a Test Record Directory
You can print a directory of all the test records stored in the CT-7000 S2’s Flash EEPROM by
using the steps below:
a. Start from the “START-UP” menu:
Press the
[3]
key (SETUP).
b. The following screen will be displayed:
Press the
[3]
key (SAVE / RESTORE).
c. The following screen will be displayed:
Press the
[3]
key (SHOT DIRECTORY).
d. The following screen will be displayed:
Press the
[1]
key (SHORT DIRECTORY) to print a directory of the last ten shots stored in
the EEPROM. The short directory will be printed, and you will be returned to the
“START-UP” menu.
Press the
[2]
key (FULL DIRECTORY) to print a directory of all the shots stored in the
EEPROM. The full directory will be printed, and you will be returned to the “START-UP”
menu.
A sample test record directory is shown in Figure 27.
1. SHORT DIRECTORY
2. FULL DIRECTORY
1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
1. TIME BRKR 02/10/11
2. GET RSLT 09:04:05
3. SETUP
4. DIAGNOSTICS
