CT-7000 S2 USER’S MANUAL REV 2
21
3.1.10. Configuring the Automatic Printing Feature
The CT-7000 S2 can be configured to print graphs and tabulated results automatically after each
test. To configure the automatic printing feature:
a. Start from the “START-UP” menu:
Press the
[3]
key (SETUP).
b. The following screen will be displayed:
Press the [4] key (NEXT PAGE).
c. The following screen will be displayed:
Press the [4] key (NEXT PAGE).
d. The following screen will be displayed:
Press the [1] key (SET PRINT MODE).
e. The following screen will be displayed:
Press the [1] key (AUTOMATIC PRINT) if you would like to automatically print tabulated
and graphic results after each test is performed.
Press the [2] key (BY REQUEST ONLY) to turn off automatic printing of test results.
Please see section 3.2.5 for instructions on how to manually print test results.
SET PRINT MODE:
1. AUTOMATIC PRINT
2. BY REQUEST ONLY
1. SET PRINT MODE
2. SET 50/60 Hz
1. SHOT DESCRIPTION
2. NUMBER OF CHANNELS
3. SET DATE & TIME
4. NEXT PAGE
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
1. TIME BRKR 02/04/11
2. GET RSLT 13:29:15
3. SETUP
4. DIAGNOSTICS
