CT-7000 S2 USER’S MANUAL REV 2
67
3.3 Working with Test Records
3.3.1. Saving a Timing Record in Flash EEPROM
After performing a test, you can store the results in the CT-7000 S2’s Flash EEPROM. To save a
test record:
a. Start from the “START-UP” menu:
Press the
[3]
key (SETUP).
b. The following screen will be displayed:
Press the [3] key (SAVE / RESTORE).
c. The following screen will be displayed:
Press the
[1]
key (SAVE SHOT).
d. The following screen will be displayed:
Press the [ENTER] key to save the test shot.
e. The following screen will be displayed:
Press any key to return to the “START-UP” menu.
SHOT SAVED
SAVE SHOT #1
TEST:STATIC RES TEST
DATE: 03/11/10 13:26
“ENTER” TO PROCEED
1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
1. TIME BRKR 02/10/11
2. GET RSLT 14:16:18
3. SETUP
4. DIAGNOSTICS
