DMOM-100/200 Series 2 Operating Procedures
7
Rev 2, 2009
1.5 Optional Accessories
1. Heavy-duty welding-type C-clamps (Figure 5.0) are available as optional accessories. These
C-clamps allow test lead connections to a wide variety of bushing sizes, bus bars, and
conductors that require low-resistance test-lead contacts.
2. Light weight (#4 AWG) cables are also available upon request.
3. Custom cable lengths are available upon request.
Figure 1.0 Combined Current and Sense Leads
Figure 2.0 DMOM-100/200 Sensing cable
Current Jaw
Voltage Jaw
