DMOM-100/200 Series 2 Operating Procedures
24
Rev 2, 2009
Table 5.0 Run Test Procedure (Measure an Unknown Resistance Continued)
STEP ACTION DMOM DISPLAY
5-14 If the tested resistance measurement is to
be stored in the test record buffer, press
key # 1 (YES). The TEST SAVED
message will be displayed. Press the
ENTER key to continue.
If the test is not to be stored in memory,
press key # 2 (NO).
5-15 The RUN ANOTHER TEST menu will
appear.
If another test is not needed, press key # 2
(NO). Go to step 5-17.
If another test needs to be run, press key #
1 (YES). The SELECT TEST
CURRENT menu will appear.
5-16 Repeat the sequence from step 5-2 to step
5-15 to run another test.
NOTE
The SELECT TEST CURRENT menu
displayed to the right is from the DMOM-
100. On the DMOM-200, option # 5 is
200A, and option # 6 is CUSTOM.
5-17 The SAVE THIS RECORD menu is
displayed when another test was not
selected in step 5-15 (by pressing key # 2).
The test record contains all the readings
taken during the test.
5-18 To save this record, press key # 1 (YES).
If the test record is not to be saved, press
key # 2 (NO), then go to step 5-20.
NOTE
A test record is saved in Flash EEPROM.
A record number will be automatically
assigned to the record by the DMOM.
(The Test record was assigned #2 in this
example).
5-19 When the record has been saved
(RECORD NUMBER “xx” is displayed),
press the ENTER key to return to the
START MENU.
1. RUN TEST 12/11/08
2. SETUP 12:24:01
3. CAL CHECK
RECORD NUMBER xx
HAS BEEN SAVED!
SAVE THIS RECORD?
1. YES
2. NO
SELECT TEST CURRENT:
1. 10A 2. 25A
3. 50A 4. 100A
5. CUSTOM
RUN ANOTHER TEST?
1. YES
2. NO
TEST SAVED
