DMOM-100/200 Series 2 Operating Procedures
28
Rev 2, 2009
Table 6.0 Run Test Procedure (Measure an Unknown Resistance Continued)
STEP ACTION DMOM DISPLAY
6-10 To save the record, press key # 1 (YES). If
the test record is not to be saved, press key
# 2 (NO) and go to step 6-12.
NOTE
The DMOM can store 96 readings per test
record.
A test record is saved in Flash EEPROM. A
record number will be automatically
assigned to the record by the DMOM (The
Test record was assigned # 2 in this
example).
6-11 After the record is saved (the record #
assigned shows on the display), press the
ENTER key to return to the START
MENU (shown to the right).
6-12 If key # 2 was pressed in step 6-10, the
ARE YOU SURE menu will appear.
Press key # 1 to not save the record. The
START menu will appear (see illustration
in step 6-11).
Press key # 2 to save the record. A screen
will appear noting that the record has been
saved (see step 6-10). Press the ENTER
key to return to the START menu.
This ends the RUN AUTOMATIC TEST procedure.
1. RUN TEST 12/11/08
2. SETUP 12:24:01
3. CAL CHECK
ARE YOU SURE?
DATA WILL BE LOST!
1. DO NOT SAVE RECORD
2. SAVE RECORD
RECORD NUMBER 2
HAS BEEN SAVED!
