DMOM-100/200 Series 2 Operating Procedures
38
Rev 2, 2009
7.13 Computer Interface Mode
A PC program is provided with each DMOM, which allows the user to download the test records
stored in the DMOM’s Flash EEPROM to a PC. The user is required to put the DMOM in
Computer Interface Mode to allow the PC running the program to access the test records stored
in the DMOM’s Flash EEPROM.
Test records can be stored on any media the PC is capable of handling. This allows the user to
store and archive test records for reviewing at any time. Test records can also be printed from the
PC to any printer which it has access to.
Use the following steps to put the DMOM in Computer Control Mode.
Table 12.0 Computer Control Mode
STEP ACTION DMOM DISPLAY
12-1 On the START MENU, press key # 2
(SETUP) to display the SETUP MENU.
12-2 On SETUP MENU, press key # 4 (NEXT
PAGE). A menu will appear with option for
computer control, setting the time, and
calibrating the unit.
12-3 Press key # 1 to select COMPUTER
CONTROL mode.
NOTE
Press the STOP key to abort.
COMPUTER ITF MODE
1. ENTER ID
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
1. COMPUTER CONTROL
2. SET TIME
3. CALIBRATE UNIT
